Report: Brazilian Ethanol is Sustainable
Posted by Robert Rapier on October 11, 2006 - 9:18am
The purpose of the study is explained in the introduction to the report:
The Dutch society recognizes the need for sustainable production and use of biomass. This has been expressed by environmental groups and the Parliament. The Dutch government decided to seek solutions by developing sustainability criteria and certification of biomass by a commission sustainable production of biomass. Between January 2006 and July 2006 these criteria have been developed. Parallel to these developments, in February 2006 this project was commissioned by SenterNovem on behalf of the Dutch Ministry for Housing, Spatial Planning and the Environment. As Brazil is one of the most likely countries to export bio-ethanol from sugar cane to the Netherlands, the sustainability of Brazilian bio-ethanol is the main topic of this report.The main objective of this report was a comparison of Dutch sustainability criteria and the current Brazilian practice, and quantification of the consequences for ethanol production in terms of production method and production costs if these sustainability criteria are applied. To this end, the Dutch sustainability demands for bio-ethanol were investigated, including stakeholder consultation in the Netherlands, and an extensive assessment of the current ecological, economic and social impacts of ethanol production based on sugar cane in Brazil was carried out.
This is precisely the kind of study that has been needed to verify that claims of Brazilian ethanol sustainability are on sound scientific footing. According to the report, there are some areas of concern, but none that should prevent Brazilian ethanol from meeting the sustainability criteria:
While the current study contains many different types of uncertainties, no prohibitive reasons where identified why ethanol from São Paulo principally could not meet the Dutch sustainability standards set for 2007. In many impact categories, Brazilian ethanol from sugar cane scores average to (very) positive, see also Table I for a summary. For a number of other criteria, problems are identified, but it also appears that these may differ strongly between the individual plants. Furthermore, for most of these issues, measures can be identified to improve performance (when needed).For the future and the whole of Brazil, too many uncertainties remain to determine whether also additional criteria from 2011 onwards can be met. First of all, it is as yet unclear how additional land use for sugar cane may cause indirect / induced land-use, and how large the actual impacts will be on land use, biodiversity etc. Second, it is also uncertain whether and how the Dutch sustainability criteria will deal with these indirect impacts, as these criteria are not yet clearly defined.
It is important to recognize that sustainability criteria lead to higher production costs - depending on the strictness of the sustainability criteria, we estimate additional ethanol costs of up to 56%, though in case mechanical green harvesting is applied, additional ethanol costs are estimated at 24%.While the latter may not necessarily be prohibitive given current oil prices, it is clear that some financial support is most likely needed to stimulate sustainable ethanol production.
The report examined a number of sustainability criteria. However, in this essay I will mention only two: EROEI and soil erosion.
What's the EROEI?
One the issue of sugarcane ethanol EROEI, which has been debated here a great deal, the study mentioned two different literature reports. The first was by Oliveira et al. in 2005, and it concluded that the EROEI was between 3.1 and 3.9. The second report was by Macedo et al. in 2004 and it concluded that the EROEI was between 8.3 and 10.2. (Note that the "bad" EROEI was still over double the EROEI of corn ethanol.) Due to the huge disparity between the two papers, the authors took a look at the underlying numbers, and concluded that the discrepancy involved the amount of diesel used in the agricultural operations process. They ultimately tracked down another paper that agreed with the Macedo study, so they reasoned that the diesel consumption numbers used by Oliviera were erroneous. They therefore concluded that an EROEI between 8.3 and 10.2 was legitimate.
Not surprisingly, the greenhouse gas (GHG) emission reduction for sugarcane ethanol was estimated to be >80%. EROEI and GHG emissions are very closely related, such that a renewable energy source possessing a high EROEI should demonstrate a high level of GHG emission reduction.
Soil Erosion
One area that did not fare as well as sugarcane ethanol advocates have often advertised is on the issue of soil erosion. I have been told a number of times that there is no erosion from sugarcane production, or that production is managed such that the topsoil actually increases over time.
While the report noted that the erosion is lower than for crops such as corn, it did note:
Soil erosion in sugar cane is generally limited compared to conventional agricultural crops such as corn and soybeans, although the exact difference is dependant on local conditions. However, soil losses for sugar cane may vary dramatically from 0.1 t/ha/y to 109 t/ha/y, depending on many factors, such as the declivity, the annual rain fall, the management and harvesting system, etc.
The report did state that data on erosion from sugarcane production was limited, and that there were some studies that suggested little to no erosion. The report also indicated that the erosion issue should be studied more closely, and that a soil erosion management plan is required. They state that new compliance criteria are to be developed for 2011. In concluding the section on soil erosion, they state:
Soil erosion during sugar cane production can be a site-specific problem. Soil erosion rates under sugar cane production are limited compared to conventional cropland, but are likely higher compared to pastures. Data on soil erosion rates under various land use types are however uncertain. Soil erosion can be prevented in various ways, although it cannot be avoided completely. Consequently, only in case very strict soil erosion rates are applied (which goes beyond the approach applied in existing certification systems and guidelines) soil erosion could be an important bottleneck for certification. As far as soil erosion can be prevented, the costs are likely in the order of magnitude of a few percent of the production costs of ethanol. We conclude that soil erosion can be regarded in general as having a medium impact factor on soil erosion.
My guess is that the last sentence in that section was supposed to read "We conclude that soil erosion can be regarded in general as having a medium impact factor on the sustainability criteria."
Implications for Tropical Countries
Based on the findings in the report, it suggests that many tropical countries have the potential for sustainable fuel production. This should be particularly true of any country that can grow excess sugarcane according to Brazil's methods. The major caveat is that the soil erosion issue must be appropriately managed. Not only would this help certain countries achieve some level of energy security, but excess fuel produced for export would open up new opportunities for farmers, factory workers, etc. and generate income for the country.
Implications for the U.S.
The reason the Netherlands commissioned this study is that they want to transition to fuels that are produced in a sustainable manner. If Brazil or other tropical countries can produce enough fuel for export, it will benefit the U.S. just like it will benefit the Netherlands. However, the U.S. does have an import tariff in place that penalizes Brazilian ethanol in order to protect (unsustainable) homegrown corn ethanol.
One way the Brazilian example does not benefit the U.S. is in providing a template for success. As I have argued previously, Brazil's particular situation is not applicable in the U.S. As I wrote in an article for World Energy Source, the U.S. uses 7 times the energy per capita that Brazil does. Our supply/demand imbalance gap is 16.9 barrels per person per year. Theirs was 0.2 barrels per person last year, prior to the opening of a new Petrobras platform earlier in the year (immediately after which they declared energy independence). Furthermore, we rely on a crop (corn) in the U.S. that is much less energy efficient, and has ten times the soil erosion of sugarcane production. Finally, we are not in a tropical climate, and therefore have a much shorter growing season than does Brazil.
Brazilian ethanol expert Milton Maciel, has echoed these arguments:
Sugar cane ethanol from Brazil is NOT a realistic target or a comparable model for USA ethanol from corn. It is very easy to replace all gasoline when you would only need 8 billion gallons per year and you have a generous plant that thrives rain-fed under tropical conditions, occupying less than 1% of a country's arable land, to produce alcohol to replace 50% of all that gasoline. However, this cannot be extrapolated for USA's conditions, neither for corn, not even for sugar cane in Southern states. So, realistically, let's understand that sugar cane ethanol in Brazil is mangoes and corn ethanol in USA is apples.
Pipedreaming
The Brazilian example does suggest some avenues ripe for exploration in the U.S. There are certain crops that are far less erosive than others. According to Table K.1 in the report, soil erosion for sugarcane and corn was 1.24 and 12.0 (t/ha/y) respectively. Note that erosion from corn is 10 times the erosion from sugarcane. Another listed crop, potatoes, had about half the erosion level of corn. However, the level of erosion for potatoes is still not sustainable, so we need to look to other crops if we are to maintain the integrity of our topsoil.
Imagine a couple of scenarios. First, imagine a variety of sugarcane that is bred/engineered to withstand more temperate climates. Imagine the Midwest covered in sugarcane instead of corn, and we would have taken a big step toward sustainability. Alternatively, imagine a plant that currently thrives in the Midwest, does not contribute to soil erosion, and produces sugar (easily converted to ethanol). I could envision something like Miscanthus, with an engineered gene(s) that allows it to produce sugar. If you have ever seen the ancestor of corn - teosinte - and compared it to modern corn, this idea does not seem out of the question. Again, if we could pull something like that off in the U.S., it could offset some of the decline in conventional oil production without exacting the high environmental price of alternatives like coal-to-liquids.
Selective Breeding Turned Teosinte into Modern Corn
Conclusions
The sustainability of Brazilian ethanol appears for the most part to be as advertised. The indications are that the EROEI is at least 8.3, which would actually make it better than for gasoline. (Incidentally, that brings to mind the question of why Brazil would want to export any ethanol; I would use my ethanol internally and would export my oil instead). The sustainability criteria that were used in this study are an example of what we should be doing for all of our fuel sources, and we should encourage those that meet these standards.
[editor's note, by Prof. Goose] If you would like to see Robert's engagement of venture capitalist Vinod Khosla (which was done over three or four posts), you can either search for it over in the right sidebar, or you could go up to the title of the post and click "all tags" and then search for Khosla's name or ethanol or whatever else you want to read about. That's what the tags are for!
